10.1-inch Rugged Vehicle Tablet for Various Industrial Applications
Powered by Android 13 and an octa-core processor, AT-10A Pro integrates comprehensive communication modules and high-precision positioning capabilities, making it ideal for a variety of industrial applications.
Powered by Android 13, it ensures consistent, stable and reliable performance with seamless and efficient operation of applications.
Equipped with a 10-inch 1200 nits high-brightness display, the tablet delivers clear and easy-to-read visuals in bright outdoor environments.
Support GPS, GLONASS, BDS, Galileo satellite positioning systems, with multiple positioning accuracy options, which can meet the application demands of vehicle positioning, precision agriculture, etc.
The built-in RTK supports real-time GNSS corrections, delivering positioning accuracy of up to ±2.5 cm. It is ideal for precision agriculture, mining, and other applications, helping improve operational accuracy and efficiency.
With an IP67 rating, the tablet is protected against dust, high-pressure water jets, and temporary immersion in up to 1 meter of water, ensuring reliable operation in harsh environments.
Designed for reliable operation from -10°C to 65°C, the tablet delivers stable performance in demanding industrial environments.
Equipped with a built-in 10F supercapacitor, the important data can be saved promptly in the event of a sudden power outage.
Compliant with ISO 7637-II transient voltage protection standard, the tablet can withstand up to 174V 300ms vehicle surge impact. Wide voltage design of DC 8–36V, adaptable to most vehicle power supplies.
| System | |
| CPU | Qualcomm 64-bit Octa-core processor, up to 2.0 GHz |
| GPU | Adreno 610 |
| Operating System | Android 13 |
| RAM | LPDDR4 4GB (default)/8GB (optional) |
| Storage | eMMC 64GB (default)/128GB (optional) |
| Functional Module | |
| LCD | 10 Inch Digital IPS Panel, 1280×800, 1200 nits |
| Screen | Multi-point capacitive touch screen |
| Audio | Integrated microphone, integrated speaker 2W |
| Interface | Type-C 3.0×1 (Type-A and Type-C cannot be used simultaneously) |
| Micro SD card slot×1, support up to 1TB | |
| Nano SIM card slot×1 | |
| 3.5mm earphone jack×1 (compliant with CTIA standard) | |
| Sensors | Acceleration, gyro sensor, compass, ambient light sensor |
| Environmental Reliability | |
| IP Rating | IP67 |
| Vibration Test | MIL-STD-810G |
| Operating Temperature | -10°C ~ 65°C (14°F ~ 149°F) |
| Storage Temperature | -20°C ~ 70°C (-4°F ~ 158°F) |
| Physical Characteristics | |
| Power | DC8-36V (ISO 7637-II compliant) |
| Supercapacitor | 10F |
| Physical Dimensions | 273×183×49mm (W×H×D) |
| Weight | 1.6kg |
| Extended Interfaces | |
| Power Cable |
Power input×1 (DC 8-36V) |
| ACC×1 | |
| Power output×1 (The power input interface loops out the | |
| power supply, and the maximum output current is 2A.) | |
| Port A Cable | RS232×2 |
| RS485×1 | |
| CAN Bus×1 | |
| GPIO×7 | |
| Port B Cable
(Optional) |
AHD input×4, support 720P/1080P resolution, PAL/NTSC |
| CAN Bus×1 | |
| RJ45 (10/100)×1 | |
| Communication | |
| Bluetooth | 2.1+EDR/3.0/4.1 LE/4.2 BLE/5.0 LE |
| WLAN | 802.11a/b/g/n/ac, 2.4GHz&5GHz |
| 4G (US Version) | LTE FDD: B2/B4/B5/B7/B12/B13/B14/B17 |
| /B25/B26/B66/B71 | |
| LTE-TDD: B41 | |
| 4G (EM Version) | LTE FDD: B1/B2/B3/B4/B5/B7/B8/B20/B28 |
| LTE TDD: B38/B39/B40/B41 | |
| WCDMA: B1/B2/B4/B5/B8 | |
| GSM: 850/900/1800/1900MHz | |
| GNSS (Standard) | GPS/GLONASS/BDS/Galileo/QZSS |
| position accuracy: 2.5m | |
| GNSS (Optional) | GPS/GLONASS/BDS/Galileo/QZSS/SBAS, |
| position accuracy: 1.5m CEP(with SBAS), 2.0m CEP(without SBAS) |
|
| NFC (Optional) | · ISO/IEC 14443A, ISO/IEC 14443B PICC mode |
| · ISO/IEC 14443A, ISO/IEC 14443B PCD mode | |
| designed according to NFC Forum | |
| · Digital protocol T4T platform and ISO-DEP | |
| · FeliCa PCD mode | |
| · MIFARE PCD encryption mechanism (MIFARE 1K/4K) | |
| · NFC Forum tags T1T, T2T, T3T, T4T and T5T, | |
| NFCIP-1, NFCIP-2 protocol | |
| · NFC Forum certification for P2P, reader and card mode | |
| · FeliCa PICC mode | |
| · ISO/IEC 15693/ICODE VCD mode | |
| NFC Forum-compliant embedded T4T for NDEF short record | |
| eSIM (Optional) | ×1 |
| High Precision Position (Optional) | |
| Built-in Digital
Radio Station |
Support communication frequency 410-470Mhz |
| Support protocols: TRIMTALK, TRIMMK3, TT450S, | |
| TRANSEOT, SOUTH, HUACE, SATEL | |
| Support communication rates: 9600bps,19200bps | |
| Max transmission distance: 3-5km (unobstructed area) | |
| RTK Position Module
(Domestic Version) |
Single point position (RMS): 1.5m horizontally, 2.5m vertically |
| DGPS (RMS): 0.4m horizontally, 0.8m vertically | |
| RTK (RMS): 0.8cm+1ppm horizontally, 2.5cm+1ppm vertically | |
| Data format: NMEA-0183 | |
| Support input differential format RTCM3.X | |
