VT-BOX
Intelligent Vehicle Telematics Terminal with Android OS.
VT- Box is an Intelligent Vehicle Telematics Terminal with Android and wire/wireless communication.
Feature
Qualcomm CPU and Android OS
Built in Qualcomm quad-core CPU and Android Operation System, provide a flexible development environment and application.
Qualcomm CPU and Android OS
Built in Qualcomm quad-core CPU and Android Operation System, provide a flexible development environment and application.
Qualcomm CPU and Android OS
Built in Qualcomm quad-core CPU and Android Operation System, provide a flexible development environment and application.
Qualcomm CPU and Android OS
Built in Qualcomm quad-core CPU and Android Operation System, provide a flexible development environment and application.
Qualcomm CPU and Android OS
Built in Qualcomm quad-core CPU and Android Operation System, provide a flexible development environment and application.
Specification
| System | |
| CPU | Qualcomm Cortex-A7 Quad-core processor, 1.1GHz |
| GPU | Adreno 304 |
| Operating System | Android 7.1.2 |
| RAM | 2GB |
| Storage | 16GB |
| Communication | |
| Bluetooth | 4.2BLE |
| WLAN | IEEE 802.11a/b/g/n; 2.4GHz/5GHz |
| Mobile Broadband
(North America Version) |
LTE FDD: B2/B4/B5/B7/B12/B13/B25/B26
WCDMA: B1/B2/B4/B5/B8 GSM: 850/1900MHz |
| Mobile Broadband
(EU Version) |
LTE FDD: B1/B3/B5/B7/B8/B20
LTE TDD: B38/B40/B41 WCDMA: B1/B5/B8 GSM: 850/900/1800/1900MHz |
| Mobile Broadband
(AU Version) |
LTE FDD: B1/B3/B5/B7/B8/B28
LTE TDD: B40 WCDMA: B1/B2/B5/B8 GSM: 850/900/1800/1900MHz |
| GNSS | GPS/GLONASS/BEIDOU |
| Functional Module | |
| Interfaces | CAN Bus x 1 |
| GPIO x 2 | |
| ACC x 1 | |
| Analog input x 1 | |
| RS232 x 1 | |
| Power x 1 | |
| Sensors | Acceleration |
| Physical Characteristics | |
| Power | DC8-36V (ISO 7637-II compliant) |
| Physical Dimensions (WxHxD) | 133×118.6x35mm |
| Weight | 305g |
Accessories
External Antenna
External Antenna
External Antenna
